Details

Advertised Engine Power, Rated, hp (kW) - 75 (55)
Maximum Engine Power, hp (kW) - Same as advertised
Rated Engine Speed, rpm - 2300
Power Boost, hp (kW) - No boost
Fuel Tank capacity, gal (L) - 19.6 (74)
Diesel Exhaust Fluid (DEF) tank capacity, gal (L) - No DEF
Engine Make - FPT
Engine Model - F5DFL413C-E
Number of Cylinders - 4
Displacement, cu in (L) - 207 (3.4)
Engine Bore, in (mm) - 3.90 (99)
Engine Stroke, in (mm) - 4.33 (110)
Block Design, Replaceable Liners - Parent bore block
Aspiration, Turbocharged or Naturally Aspirated - Turbocharged
Fuel System Description - High Pressure Common Rail
Fuel System Control, Electronic or Mechanical - Electronic
Fuel Injection to combustion chamber, Direct or Indirect - Direct
Emission Level, US EPA Tier - Tier 4 Final
Selective Catalytic Reduction (SCR) w/Diesel Exhaust Fluid (DEF) - No
Exhaust Gas Recirculation (EGR) - Cooled EGR
Cleanup Catalyst (CUC) - No
Diesel Oxidation Catalyst (DOC) - DOC standard
Diesel Particulate Filter (DPF) - Passive, automatic
Exhaust Pipe, Vertical stack or Horizontal - Horizontal
Cooling System Fan Drive Type - Viscous
Electrical System Rating, Volts - 12
Alternator Rating, Amps - 95
